**OpenAPI/Swagger-generated API Reference Documentation** [](https://travis-ci.org/Rebilly/ReDoc) [](https://coveralls.io/github/Rebilly/ReDoc?branch=master) [](https://APIs.guru) [](https://david-dm.org/Rebilly/ReDoc) [](https://david-dm.org/Rebilly/ReDoc#info=devDependencies) [](https://www.npmjs.com/package/redoc) [](https://github.com/Rebilly/ReDoc/blob/master/LICENSE) **REACT-REWRITE: WORK IN PROGRESS** To try locally run: ```shell yarn install npm start ```  ## [Live demo](http://rebilly.github.io/ReDoc/) [](https://github.com/Rebilly/generator-openapi-repo#generator-openapi-repo--) [](https://redoc.ly) [](https://redoc.ly/#services) ## Features - Extremely easy deployment - The widest OpenAPI v2.0 features support (yes, it supports even `discriminator`)
 - Neat **interactive** documentation for nested objects
 - Code samples support (via vendor extension)
 - Progressive loading with `lazy-rendering` options
 - Responsive three-panel design with menu/scrolling synchronization - Integrate API Introduction into side menu - ReDoc takes advantage of markdown headings from OpenAPI description field. It pulls them into side menu and also supports deep linking. - High-level grouping in side-menu via [`x-tagGroups`](docs/redoc-vendor-extensions.md#x-tagGroups) vendor extension - Multiple ReDoc instances on single page ([example](demo/examples/multiple-apis/index.html)) ## Roadmap - [ ] [OpenAPI v3.0 support](https://github.com/Rebilly/ReDoc/issues/312) - [x] ~~performance optimizations~~ - [x] ~~better navigation (menu improvements + search)~~ - [ ] ability to simple branding/styling - [ ] built-in API Console - [ ] docs pre-rendering (performance and SEO) ## Releases We host the latest and all the previous ReDoc releases on GitHub Pages-based **CDN**: - particular release, e.g. `v1.2.0`: https://rebilly.github.io/ReDoc/releases/v1.2.0/redoc.min.js - `v1.x.x` release: https://rebilly.github.io/ReDoc/releases/v1.x.x/redoc.min.js - `latest` release: https://rebilly.github.io/ReDoc/releases/latest/redoc.min.js this file is updated with each release of ReDoc and may introduce breaking changes. **Not recommended to use in production.** Use particular release or `v1.x.x`. ## Version Guidance | ReDoc Release | OpenAPI Specification | |:--------------|:----------------------| | 1.19.x | 2.0 | | 1.18.x | 2.0 | | 1.17.x | 2.0 | ## Some Real-life usages - [Rebilly](https://rebilly.github.io/RebillyAPI) - [Docker Engine](https://docs.docker.com/engine/api/v1.25/) - [Zuora](https://www.zuora.com/developer/api-reference/) - [Shopify Draft Orders](https://help.shopify.com/api/draft-orders) - [Discourse](http://docs.discourse.org) - [APIs.guru](https://apis.guru/api-doc/) ## Deployment ### TL;DR ```html ``` That's all folks! **IMPORTANT NOTE:** if you work with untrusted user spec, use `untrusted-spec` [option](#redoc-tag-attributes) to prevent XSS security risks. ### 1. Install ReDoc (skip this step for CDN) Install using [bower](bower.io): bower install redoc or using [npm](https://docs.npmjs.com/getting-started/what-is-npm): npm install redoc --save ### 2. Reference redoc script in HTML For **CDN**: ```html ``` For bower: ```html ``` For npm: ```html ``` ### 3. Add `` element to your page ```html ``` ### 4. Enjoy :smile: ## Configuration ### Security Definition location You can inject Security Definitions widget into any place of your specification `description`. Check out details [here](docs/security-definitions-injection.md). ### Swagger vendor extensions ReDoc makes use of the following [vendor extensions](http://swagger.io/specification/#vendorExtensions): * [`x-logo`](docs/redoc-vendor-extensions.md#x-logo) - is used to specify API logo * [`x-traitTag`](docs/redoc-vendor-extensions.md#x-traitTag) - useful for handling out common things like Pagination, Rate-Limits, etc * [`x-code-samples`](docs/redoc-vendor-extensions.md#x-code-samples) - specify operation code samples * [`x-examples`](docs/redoc-vendor-extensions.md#x-examples) - specify JSON example for requests * [`x-nullable`](docs/redoc-vendor-extensions.md#nullable) - mark schema param as a nullable * [`x-displayName`](docs/redoc-vendor-extensions.md#x-displayname) - specify human-friendly names for the menu categories * [`x-tagGroups`](docs/redoc-vendor-extensions.md#x-tagGroups) - group tags by categories in the side menu * [`x-servers`](docs/redoc-vendor-extensions.md#x-servers) - ability to specify different servers for API (backported from OpenAPI 3.0) * [`x-ignoredHeaderParameters`](docs/redoc-vendor-extensions.md#x-ignoredHeaderParameters) - ability to specify header parameter names to ignore ### `` tag attributes * `spec-url` - relative or absolute url to your spec file; * `untrusted-spec` - if set, the spec is considered untrusted and all HTML/markdown is sanitized to prevent XSS. **Disabled by default** for performance reasons. **Enable this option if you work with untrusted user data!** * `scroll-y-offset` - If set, specifies a vertical scroll-offset. This is often useful when there are fixed positioned elements at the top of the page, such as navbars, headers etc; `scroll-y-offset` can be specified in various ways: * **number**: A fixed number of pixels to be used as offset; * **selector**: selector of the element to be used for specifying the offset. The distance from the top of the page to the element's bottom will be used as offset; * **function**: A getter function. Must return a number representing the offset (in pixels); * `suppress-warnings` - if set, warnings are not rendered at the top of documentation (they still are logged to the console). * `lazy-rendering` - if set, enables lazy rendering mode in ReDoc. This mode is useful for APIs with big number of operations (e.g. > 50). In this mode ReDoc shows initial screen ASAP and then renders the rest operations asynchronously while showing progress bar on the top. Check out the [demo](\\rebilly.github.io/ReDoc) for the example. * `hide-hostname` - if set, the protocol and hostname is not shown in the operation definition. * `expand-responses` - specify which responses to expand by default by response codes. Values should be passed as comma-separated list without spaces e.g. `expand-responses="200,201"`. Special value `"all"` expands all responses by default. Be careful: this option can slow-down documentation rendering time. * `required-props-first` - show required properties first ordered in the same order as in `required` array. * `no-auto-auth` - do not inject Authentication section automatically * `path-in-middle-panel` - show path link and HTTP verb in the middle panel instead of the right one * `hide-loading` - do not show loading animation. Useful for small docs * `native-scrollbars` - use native scrollbar for sidemenu instead of perfect-scroll (scrolling performance optimization for big specs) ## Advanced usage Instead of adding `spec-url` attribute to the `` element you can initialize ReDoc via globally exposed `Redoc` object: ```js Redoc.init(specOrSpecUrl, options) ``` `specOrSpecUrl` is either JSON object with specification or an URL to the spec in `JSON` or `YAML` format. `options` is javascript object with camel-cased version of `` tag attribute names as the keys, e.g.: ```js Redoc.init('http://petstore.swagger.io/v2/swagger.json', { scrollYOffset: 50 }) ``` ----------- ## Development #### Running local dev-server - Clone repository `git clone https://github.com/Rebilly/ReDoc.git` - Go to the project folder `cd ReDoc` - Install dependencies `npm install` - _(optional)_ Replace `demo/swagger.yaml` with your own schema - Start the server `npm start` - Open `http://localhost:9000` Alternatively, Docker can be used by just running `docker-compose up`.
